Silver Plating Process
Rectifier Capacity :
8 Volt - 25/50/100 Amps CVCC
With deamer and digital meters
Additional facility : Timer, Amp Totalizer, Dozing pump for Brighteners.
Tank :
Fabricated with MS and Rubber Lined/ PVC lined
Fabricated with PP with wall thickness of 10/12 mm
Additional facility : Anode-Cathode Brackets, Cathode movement.
Barrel :
1/5/7.5 Kg Capacity of Loading, along with Tank and Gear Box, with Drum Hole size at 2 or 3 mm as per requirement.
FIlter Pump :
30 LPM Magnetic Pump with PP Chamber and Cartage/Pad Filtration system.
Operating Parameters :
| Temperature : | 20 to 30 ° C. |
| Voltage : | 1 to 4 Volt DC. For VAT and 6 to 8 Volt for Barrel |
| Current : | 5 to 20 Amps/ Sq. Ft. |
| Bath Composition : Silver As Metal | 15- 35 gms/ltr |
| Pottasium Cyanide : | 140 – 200 gm/ltr. |
| Carbonate : | 15 - 35 gms/ltr. |
| Carrier Brightener(M ) : | 15 – 20 ml/ltr. |
| Replainiser Brightner(R ) : | 1- 2 ml/ltr. |
| Anodes : | Pure Silver Metal @ purity of 99.99% |
| Rate of Deposition : | 25 micron in 20 min @ 20 Amp/sq.ft. |
| Filtration : | 2 hrs of working days. |
| Brightener maintenance : | (M) @ 50 to 75 ml/ KAH (R ) @ 350 to 450 ml/KAH |
