| Model No : MDC-9601 |
|
|
|
|
| |
| Specifications : |
| Range |
999.9/9999 counts |
| Display |
Upper 4D (RED), Running Count (0.56") Lower 4D (GREEN), Set Count (0.4") |
| Input |
NPN Proximity, Moon Switch, Limit Switch Encoder or 230V Ac Pulse |
| Output |
1 C/O Relay 5Amp 230V Ac |
| Reset |
Manual / Auto reset selectable by key pad (Reset time selectable by keys in auto mode) |
| Count Rate |
Low speed upto 1000 pulse/min |
| Supply |
230V/110V Ac ±10%, 50 hz |
| Optional |
Reset of Back terminals |
| |
Dual set point
Buzzer Output
Programmable scale factor
Up-Down Counter (to Encoder input)
Down counti |
|
| Model Series |
MDC-9601, MPC-9601 |
MDC-7201, MPC-7201 |
MDC-4801, MPC-4801 |
| Size (mm) |
96 x 96 |
72 x 72 |
48 x 96 |
| Cutout (mm) |
92 x 92 |
68 x 68 |
44 x 92 |
| Depth (mm) |
120 |
120 |
120 |
| Mounting |
Flush Panel Mounting |
Flush Panel Mounting |
Flush Panel Mounting |
|
| . |
|
|
|
|
|
|
|
|
|
